Express Speed Butyl Extruder machine for Insulating Glass with New Technolgy LJJT01
The type of LJTB01 butyl extruder machine is used for spreading aluminum spacer frames evenly with hot melt butyl. This equipment use large electrical control panel which makes the operation more easier. The conveyor of aluminum is controlled by frequency converter, and the speed can be adjusted from 0m/min to 47m/min, which has the fastest speed in China. It is very popular with energy-saving. Its squeezing system adopts pneumatic and hydraulic supercharging system, which makes the squeezing pressure more stable. The dispensing cylinder uses vertical rotary support system and it makes the refill of butyl easier. It can prolong the life of squeezing system and set the heating time in 24 hours with electricity and air pressure. The distance of squeezing head can be adjusted automatically according to different aluminum spacer. The machine has reached the worldwide technology with the characteristic of complete function and stable working mode.
Main feature
· Touch-screen operation, which makes the machine simple and practical
· Stable temperature and it is convenient to adjust the sealing material automatically
· According to the changed coating speed
· Recognize the aluminum spacer size automatically
♦♦♦Easy to change butyl system
♦♦♦Automatic spacer width control
♦♦♦Shape spacer model
♦♦♦Germany Siemen system
| Squeeze pressure | 10-18MPa |
| Temperature | 110~140℃ |
| Aluminum spacer width | 4-30mm |
| Speed | 0-47m/min |
| Diameter of butyl cylinder | 200mm |
| Air supply | 0.4m³/min |
| Air pressure | ≥0.6MPa |
| Total power | 380V, 5KW, 50HZ |
| Dimension | 2600×680×1100mm(L×W×H) |
| Weight | 650kg |
Automatic Butyl Robot
Main feature
· PLC control system, touch screen interface.
· Frequency control system
· Abroad technology, pneumatic and hydraulic supercharging system.
· Automatic centering and clamping structure.
· Separate extruder head structure.
· Automatic butyl volume display function.
· Circular arc butyl sealing structure.
· Extruder head height adjustment structure
· Preheating function Butyl cylinder swing mechanism
· Important control parts adopt imported brand.
technical parameter
| Squeeze pressure | 10-14MPa |
| Temperature | 110-140ºC |
| Aluminum spacer width | 6-24mm |
| Speed | 0-27m/min |
| Diameter of butyl cylinder | 190mm |
| Air supply | Flow:0.4m/min |
| Air pressure | ≥ 0.8MPa |
| Total power | 220V 50HZ 2.5KW |
| Dimension | 3000*620*1102mm
|
