Vertical Insulating Glass Sealing Equipment For Hollow Glass Double Glazing

Name: Vertical Insulating Glass Sealing Equipment For Hollow Glass Double Glazing
Brand: Jinan Lijiang Glass Machinery
Price: 1 USD

Quality Vertical Insulating Glass Sealing Equipment For Hollow Glass Double Glazing for sale

Brand Name : Jinan Lijiang Glass Machinery

Certification : CE & ISO9000

Place of Origin : Jinan City, Shandong Province, China

MOQ : 1 set

Price : Negotiated Price

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : Glass Deep-processing

Delivery Time : 5-8 working days

Packaging Details : Wooden Cases Package

Product name : Automatic Vertical Insulating Glass Sealing Equipment

Dimension(L*W*H) : 8700*2000*3500mm

Max glass size : 2500*4000mm

Min glass size : 280*450mm

Glass thickness : 12 - 50mm

Working speed : 5~40 m/min

Voltage power : 380V 12KW

Warranty : 1 Year

Contact Now

Automatic Vertical Insulating Glasing Sealing Equipment for Hollow Glass Double Glazing Processing

Product Description

Vertical Insulating Glass Sealing Equipment For Hollow Glass Double Glazing

Automatic Vertical Insulating Glass Sealing Robot

Insulating Glass automatic sealant machine can apply the mixed sealant evenly to the outer channel of the insulating glass through the servo mechanism to help the sealing and bonding performance of the insulating glass. Automatic Vertical Insulating Glass Sealing Robot can apply the mixed sealant evenly to the outer channel of the insulating glass through the servo mechanism to help the sealing and bonding performance of the insulating glass.

Advantages & Features

Benefits & Advantages

•Japan Yaskawa servo system control, full automatic and high-efficiency sealing machine •4 sections, can storage glass •Adopt timing belt, smooth transfer and accurate position •Automatically repair glass corners with scraper and roller •Automatically measure glass size, glue depth (30mm) •Every auto-function is with manual operation •Can coat double glass •Shape glass with optional edges, step glass, triple glass (Optional) •One set of booster pump controls two groups of sealants (Optional) •Can use silicone, polysulfide and silicone structural sealants •Glue head is in the front of the machine, which is easy for coating step glass •Can be connected with insulating glass processing line •With code scanning function (Optional)

The Smooth Glue Surface

After applying glue, It will ensure that the corners of the glass are full, without bubbles and other impurities, and the glue surface is so smooth.

The High-precision Servo Control System

It adopts Japanese Yaskawa servo control system with clear wiring layout to ensure stable overall performance of the equipment.

The Glass Coating

Automatically measure glass size, glue depth and glue speed through linear adjustment to ensure the stability of insulating glass coating quality.

Glue Pump A and Glue Pump B

Equipped with a single A component and a single B component, mixed and glued. When applying glue, glue pump A and glue pump B are automatically mixed to realize automatic proportioning.

Main Technical Parameter

Item.	Spec.
Max glass size	2500*4000mm
Min glass size	280*400mm
Glass thickness	12 - 50mm
Glue depth	≤22mm
Glue width	26.5mm
Working speed	5 - 40m/min
Air pressure	0.6MPa
Squeeze pressure	32MPa
Voltage Power	380V 50Hz 12KW
